16-Channel Premium Mixing Console.


Not just for live bands and DJ's, the MG Series mixing consoles can easily adapt to a truly impressive range of applications from portable PA to fixed installation. Now with the newly added digital functions and superior sound of the MGP, the possibilities are endless.


  • Studio-grade Discrete Class A “D-PRE” Mic Preamps with an Inverted Darlington Circuit
  • Musical X-pressive EQ based on Yamaha’s famed VCM Technology
  • Professional 1-knob Compressors with LED Indicators
  • High-grade Dual Digital Effects Processors: Advanced REV-X and Classic SPX
  • Stereo Hybrid Channels utilizing a Powerful, Proprietary DSP
  • Digital Connectivity for iPod/iPhone
  • MGP Editor for Detailed Control of the Console's DSP settings via iPod/iPhone
  • Rugged, Impact-resistant, Powder-coated Metal Chassis
  • Integrated Rack-ears for Easy Rack Mounting
  • Internal Universal Power Supply for World-wide Use
  • 10 Mic Inputs with 48V Phantom Power and HPF per Channel
  • Additional 2TR Inputs Provided to Accept the Output from Analog Devices or iPod/iPhone
  • 16 Line Inputs (8 mono and 4 stereo)
  • 4 GROUP Buses + ST Bus
  • 2 AUX Sends + 2 FX Sends

From the preamps, EQ and effects to the Hybrid Channel functions and iPod/iPhone connectivity—every aspect, every feature, every sound, establishes the MGP as a premium mixing console in a class of its own.

Outline

Mixing capability Mixing channels 16 Line Inputs (8 mono and 4 stereo)
GROUP 4 GROUP Buses + ST Bus
AUX 2 AUX Sends + 2 FX Sends
Input channel functions Compressor CH1-8,HPF(100Hz 12dB/oct), CH EQ(MONO) ±15dB(Max.):High 8kHz shelving/ Mid 250Hz-5kHz peaking(CH1-8,13-16)/ Low 125Hz shelving, CH EQ(STEREO) ±15dB(Max.):High 8kHz shelving/ Mid 2.5kHz peaking(CH9-12)/ Low 125Hz shelving
On-board processors FX1:REV-X(8 PROGRAM, PARAMETER control), FX2:SPX (16 PROGRAM, PARAMETER control)
I/O Mic inputs MIC: 10
Phantom power 48V phantom power per channel
Line inputs LINE: 8mono+4stereo, CH INSERT: 8, RETURN: 1stereo, 2TR IN: 1 stereo
Digital I/O USB Audio USB IN: iPod, iPhone exclusive

General specifications

Total harmonic distortion 0.02% (20Hz-20kHz@ +14dBu)
Frequency response +0.5/-1.0dB 20Hz - 20kHz, refer to the nominal output level @1kHz
Hum & noise level Equivalent input noise -128 dBu (20Hz–20 kHz, Rs=150Ω, Input Gain = Maximum)
Residual output noise -102 dBu (20Hz–20 kHz, Rs=150Ω, Input Gain = Maximum)
Crosstalk -74dB @ 1kHz
Power requirements 100-240V 50Hz/60Hz
Power consumption 55W max
Dimensions W 447mm
H 143mm
D 495mm
Net weight

Write a review

Note: HTML is not translated!
    Bad           Good

Yamaha MGP16X

  • UPC:
  • Availability: Call Us
  • 61,000.00 МКД
